Brakelight
03/08/15 at 06:29:21

Hey guys,

Recently I wrapped my exhaust pipe and after putting it back into place my brake light is on. When I turn off the lights it goes out as well and wont respond when I hit the brakes.

Someone told me I had to adjust the brake light switch. Where is it? Close to the foot peg of at the rear (the cable that runs up close to the end of my exhaust pipe)

It would be nice if the people behind me can so me hitting the brakes Wink

English is not my native tong, so sorry for the grammar :/

IP Logged

Dave

YaBB Moderator
ModSquad

Offline

SuzukiSavage.com
Rocks!

Posts: 17832
Camp Springs, Kentucky
Gender: male

Re: Brakelight
Reply #1 - 03/08/15 at 06:53:34

If you look at the foot pedal up at the front of the bike, you will see the large cable that operates the rear brake. You will also see a smaller cable attached to the pedal, and that small cable runs back to the switch that operates the brake light, and the switch is located on the frame behind the right frame cover...up behind the battery.

You must have done something that made the cable too tight.

Someday I will be old......But not today!

IP Logged

TheNewBee1

YaBB Newbies

Offline

Just Roll

Posts: 16
Maastricht, the Netherlands
Gender: male

Re: Brakelight
Reply #2 - 03/18/15 at 00:39:04

Thanks for the info! Turns out my front brake was jamming so that was the reason it wouldn't turn off.

Good thing that you told me where i could find the cable that opperates the rearbrake signal. Close inspection revealed it had snapped and now it is to short to fix it. I am going to have to replace that cable but long story short, problem fixed!

Love this forum


English is not my native tong, so sorry for the grammar :/

IP Logged

Dave

YaBB Moderator
ModSquad

Offline

SuzukiSavage.com
Rocks!

Posts: 17832
Camp Springs, Kentucky
Gender: male

Re: Brakelight
Reply #3 - 03/18/15 at 05:43:07

If you need a new rear brake cable and plan to order it.....I can save you a bit more time and effort.

In the parts diagram....the cable for the rear brake light is in the diagram for the controls mounted on the handlebars (Don't ask me why).

Part number 58830-24B01

http://www.hondaofflorence.com/fiche_section_detail.asp?section=432146&catego...

Someday I will be old......But not today!

IP Logged

TheNewBee1 YaBB Newbies Offline Just Roll Posts: 16 Maastricht, the Netherlands Gender:	Re: Brakelight Reply #4 - 03/18/15 at 13:00:10 Thanks for the effort but I don't think they will ship to the Netherlands
Back to top	English is not my native tong, so sorry for the grammar :/ IP Logged

Dave

YaBB Moderator
ModSquad

Offline

SuzukiSavage.com
Rocks!

Posts: 17832
Camp Springs, Kentucky
Gender: male

Re: Brakelight
Reply #5 - 03/18/15 at 13:23:38

TheNewBee1 wrote on 03/18/15 at 13:00:10:

Thanks for the effort but I don't think they will ship to the Netherlands Wink

I didn't expect you to buy it from the Honda of Florence site - but I wanted you to know the part number and where find it in the parts diagram. Even seasoned parts folks most likely would have trouble finding the rear brake cable for this bike....when it is located with the handlebar stuff!

Someday I will be old......But not today!

IP Logged

TheNewBee1 YaBB Newbies Offline Just Roll Posts: 16 Maastricht, the Netherlands Gender:	Re: Brakelight Reply #6 - 03/24/15 at 00:43:10 Ow thanks! I just made a few phonecalls to some scrapyards and found a full cable (with switch and spring) for under 8$ but thanks for the refrence. It did comfirm I was looking for the right part.
Back to top	English is not my native tong, so sorry for the grammar :/ IP Logged
