squeaking breaks (Read 102 times)

gdrseeker

Senior Member

Offline

Addicted!!

Posts: 365
Carson Valley NV

squeaking breaks
09/10/12 at 11:35:09

I searched and read a few posts about breaks squeaking, but still not sure what exactly to do to cure my problem. the break pads are brand new on the front and squeak like hell at lower speeds. The rear breaks are not new and also squeak. I am almost positive the squeak is in fact the breaks but I will double check today. looking for suggestions to fix the problem. I know there is break cleaner you can spray on the disk but is that a good idea?

1996 Savage, Jardine, K&N, 145 / 55 jets, 1 turn out at 5000 ft. elevation.

IP Logged

verslagen1

YaBB Moderator
ModSquad

Offline

Where there's a
will, I want to be
in it.

Posts: 28884
L.A. California
Gender: male

Re: squeaking breaks
Reply #1 - 09/10/12 at 11:41:47

Next time you're in the market, get kevlar pads, they don't squeal.

Soap and water wash is all you need otherwise.

On the back, I've done a couple of things which have eliminated the squeal. Make several hard stops till the squeal goes away. then when ever you brake/slow down, use the rears. this drives off the moisture that causes the squeal.

Also, I've modified the pads with a sharp 45° angle to push off the brake dust towards the open end. the pads have a bevel which tends to suck up the dust into the pads. the sharp edge scrapes the dust off.

Versey's Place
Tech Section Index

IP Logged

Dave YaBB Moderator ModSquad Offline SuzukiSavage.com Rocks! Posts: 18096 Camp Springs, Kentucky Gender:	Re: squeaking breaks Reply #2 - 09/10/12 at 11:50:39 There sometimes are benefits of getting older. I no longer hear squeaks very well. The stock front pads are prone to squeaking. I have not heard that anyone has a squeak from the rear. How many miles on your bike? Is it stored inside or outside? Have you ever had the rear wheel apart and/or cleaned the rear brake drum and hub?
Back to top	Someday I will be old......But not today! IP Logged

gdrseeker

Senior Member

Offline

Addicted!!

Posts: 365
Carson Valley NV

Re: squeaking breaks
Reply #3 - 09/10/12 at 12:03:40

I bought the bike for $500. It was stored in a garage for the past 10 years. The tires were old and cracked needed to replace. Nothing else wrong with the bike at all. The bike was checked over by my local shop and it only needed new front break pads. The rear still had 70%. The bike has 23K miles I have put 250 miles on it since I got it.


1996 Savage, Jardine, K&N, 145 / 55 jets, 1 turn out at 5000 ft. elevation.

IP Logged

Dave

YaBB Moderator
ModSquad

Offline

SuzukiSavage.com
Rocks!

Posts: 18096
Camp Springs, Kentucky
Gender: male

Re: squeaking breaks
Reply #4 - 09/10/12 at 13:46:33

WOW!!! A great buy.

For the rear, I would do what Verslagen suggested. Take the rear apart, clean up any dust/rust/dirt out of the hub. Use some sandpaper and remove the glaze from the shoes. Cut a few 45 degree angled slots that will help to push brake dust out toward the right side when turning forward. Might was well clean and grease the brake arm shaft while you have things apart.

Here is a link that shows a picture of a factory brake shoe with the angled cuts. I am not recommending that you buy these.....it is just an example of the angle cuts:

http://www.ebay.com/itm/EBC-Organic-X-Brake-Pads-Shoes-/330780191816?pt=Motor...

Someday I will be old......But not today!

IP Logged

justin_o_guy2 Serious Thumper Offline What happened? Posts: 55279 East Texas, 1/2 dallas/la.	Re: squeaking breaks Reply #5 - 09/10/12 at 17:08:02 Do Not Breathe the dust. do not breathe the dust. read &^ repeat as necessary.,
Back to top	The people never give up their liberties but under some delusion.- Edmund Burke. IP Logged

thumperclone Serious Thumper Alliance Member Offline PGR rider riding with respect Posts: 6050 Grand Junction Colorado Gender:	Re: squeaking breaks Reply #6 - 09/10/12 at 22:59:59 my oems squeeked like mice gettin steped on..did the brake cleaner spary a few times then got ebc's no mice no more
Back to top	standing for those who stood for US IP Logged
