White spacer mod question (Read 41 times)
JED
YaBB Newbies
*
Offline

SuzukiSavage.com
Rocks!

Posts: 32

White spacer mod question
01/21/22 at 18:22:28

Doing the white spacer mod.   It appears there’s an e-clip with about 7 positions.  What position should the clip be?

Also couldn’t I just put the clip in a lower position and then there’s no need to remove the white spacer?

Or, maybe I don’t have OEM parts.
Back to top
« Last Edit: 01/21/22 at 21:50:25 by JED »

  IP Logged
Gary_in_NJ
Serious Thumper
*****
Offline

LS650 Cafe Racer

Posts: 2629
Amongst the Twisty Roads
Re: White spacer mod question
Reply #1 - 01/21/22 at 19:20:10

Either you don’t have the correct needle for the carb, or you don’t have an OEM CV carb.
Back to top



A life-time student of motorcycling.
LS650 Cafe, DRZ400SM, FZ6N, SV650S, CB900C, Ducati ST2, CB550F-SS
My LS650=> http://suzukisavage.com/yabb2.2/Attachments/Left.JPG
  IP Logged
JED
YaBB Newbies
*
Offline

SuzukiSavage.com
Rocks!

Posts: 32

Re: White spacer mod question
Reply #2 - 01/21/22 at 22:07:37

Thanks.  It’s a Mikuni CV but the previous owner must’ve installed this different jet needle.

Does the proper needle only have one groove for the e-clip like in this photo?

Back to top


  IP Logged
zipidachimp
Serious Thumper
*****
Offline

SuzukiSavage.com
Rocks!

Posts: 1393
surrey, b.c.
Gender: male
Re: White spacer mod question
Reply #3 - 01/21/22 at 22:44:48

Yes!  I used a tiny dab of superglue on my finger and ran the spacer back and forth across a piece of sandpaper to 1/2 thickness. Use a caliper to measure it. Backfires(afterfires) much reduced.
Cheers!  Cool
Back to top


  IP Logged
