Seat lift mod with a twist !
10/13/12 at 00:36:21
I just finished my seat lift mod, which would of only taken 10 minutes but ended up taking 2 hours just trying different things to suit me. Same principal as everyone else has done but i also lifted the back of the tank. I used nolathane car shock abdorber bushes which were 20mm thick. I took out the original rubbers and put one shock bush under the tank, put the steel spacer tube in there and one above the tank mount. So remove 15mm of rubber and add 40mm of new bush to give 25mm or 1 inch of lift. By doing it this way the tank and seat seem to look right to me. At the same time I also turned the handle bar risers around 180 degrees. This put the bars forward maybe an inch and I set the bar ends slightly higher too so all up maybe 2 inches higher. Just doing this has made such a huge change in comfort for me, might not work for everyone but I thought I would share for others to think about.
Back to top
IP Logged
Scott.aust
Junior Member
Offline
SuzukiSavage.com
Rocks!
Posts: 53
Brisbane Queensland Australia
Gender:
Re: Seat lift mod with a twist !
Reply #1 -
10/13/12 at 00:41:38
Oh and the bushes cost $15 and bolts $3.50 so all up under $20 !!! ( and the dark blue is not noticeable unless you know what you are looking for )
Back to top
IP Logged
ToesNose
Serious Thumper
Offline
Pardon me, do you
have Hot Sauce?
Posts: 1993
Mooresville, NC
Gender:
Re: Seat lift mod with a twist !
Reply #2 -
10/13/12 at 04:35:33
The bushings make the mod look nice and clean, good job Scott
Back to top
The Suzuki LS650, bringing Miles of Smiles everywhere!
IP Logged
